Brief comparison

Helios2 The 3D Time of Flight (ToF) camera provides real-time 3D depth imaging with high precision and sub millimeter level accuracy. This camera features Sony's IMX566PLR ToF sensor, combined with LUCID's Factory Tough IP67 design, making it ideal for all-weather operation in challenging industrial environments.

Helios2+It is an advanced version of the Helios2 ToF camera, offering two additional modes. High dynamic range mode and high-speed ToF mode. The high dynamic range mode combines multiple exposures to provide accurate depth information in scenes containing high and low reflection objects. High speed mode uses single phase measurement to achieve depth perception, achieving faster acquisition speed and higher frame rate for moving targets, but sacrificing absolute accuracy and measurement distance range. Both HDR and high-speed mode are fully implemented through processing on the camera.

due toHelios2 WideHaving a wider 108 ° x 78 ° field of view (compared to the 69 ° x 51 ° field of view of Helios 2/2+), its visible area has increased fourfold. This allows Helios2 Wide to image larger areas at the same distance as Helios2, or the same areas at closer distances to the target, making camera installation more flexible.

All Helios2 models have the same Factory Tough industrial design, with IP67 dust and water resistance, and are 100% compatible in both mechanical and software aspects.

Helios2 ToF 3D IP67 相机
 Helios2+Helios2Helios2 WideHelios
Sensor model: Sony IMX556PLR Sony IMX556PLR Sony IMX556PLR Sony IMX556PLR
Resolution: 640 x 480 px, 0.3 MP 640 x 480 px, 0.3 MP 640 x 480 px, 0.3 MP 640 x 480 px, 0.3 MP
VCSEL wavelength: 850 nm, Indoors 850 nm, Indoors 850 nm, Indoors 850 nm, Indoors
work distance: 0.3 - 8.3 m (Normal, HDR)
      0.3 - 2.5 m (High-Speed)
0.3 - 8.3 m 0.3 - 8.3 m 0.3 - 6.0 m
temporal noise @ 1 m: 0.6 mm 0.6 mm 0.6 mm (0.72 mm*)
(*Exposure 3000 μ Filmed at time s)
1.6 mm
Accuracy (up to 1.5 meters)± 4.0 mm ± 4.0 mm ± 6.0 mm ± 5.0 mm
Horizontal/Field of View:69° x 51° 69° x 51° 108° x 78° 59° x 45°
Total amount of working distance mode: 6 Modes (Normal)
      5 Modes (HDR)
      3 Modes (High-Speed)
6 Modes6 Modes2 Modes
Total number of pixel formats: 10 888
High Dynamic Range (HDR) mode: Yes NoNoNo
High speed mode: Yes NoNoNo
Adjustable starting distance point for mode: Yes Yes Yes No
size:60 x 60 x 77.5 mm60 x 60 x 77.5 mm60 x 60 x 77.5 mm 55 x 55 x 77.5 mm
weight:398 g398 g390 g 254 g
Frame rate: HDR & Manual: 3
(62.5, 250, 1000 μs)
30 FPS (All Distance Modes) 30 FPS (All Distance Modes),
10 FPS (All distance modes use exposure of 3000µs )
30FPS (Near Mode) , 15FPS (Far Mode)
Exposure options: HDR & Manual: 3
(62.5, 250, 1000 μs)
3 (62.5, 250, 1000 μs)3 (187.5, 750, 3000 μs)2
IP67 protection: Yes Yes Yes No
power over ethernet (PoE): Yes Yes NoNo
"Flying Pixels" Filter: Yes Yes Yes No
Indoor ambient light filter: On-Camera & On-Sensor On-Camera & On-Sensor On-Camera & On-Sensor On-Sensor Only
Combining with other Helios cameras? Yes Yes Yes Yes
Combining Helios with color cameras to obtain RGB point clouds? Yes Yes Yes Yes
